Theater 500 Surround + Denon X3800H for Dolby Atmos "5.1.2"
View a similar product now.
Highlights
![Dolby Atmos [Highlight XL]](https://cdn.teufelaudio.com/image/upload/c_lfill,e_blur:500,f_auto,h_512,o_100,q_0,w_960/v1/other/pds-highligths-large-dolby-atmos.jpg)
Why we love this product
With the LT5 licensed by Dolby Atmos, you'll experience sound from every angle, including from above, thanks to innovative upfiring speakers. With its sleek aluminium columns, the system is also one of the most attractive home cinema sets on offer and Teufel's acoustic technology guarantees the very best sound experience.
![Dolby Atmos [Highlight XL]](https://cdn.teufelaudio.com/image/upload/c_lfill,e_blur:500,f_auto,o_100,q_0,w_240/v1/other/pds-highligths-large-dolby-atmos.jpg)
Key advantages at a glance
- High-end Dolby Atmos surround set with aluminium columns
- 4 upfiring Atmos speakers create a highly realistic 3D sound
- World’s first Dolby Atmos set with four active upfiring speakers
- 3-way system for true-to-source playback with music, movies and games
- Subwoofer with giant 300 mm woofer for extraordinary bass performance
- Elegant design with brushed aluminium and steel hardware elements
Features
All technologies at a glance
Refined bass power
The S 6000 SW is an advanced model universal subwoofer from Teufel: engineered in Berlin. Overview of highlights:
- Front-firing for refined sound production
- 300 mm chassis for cut-off frequencies down to 25 Hz
- Nearly double sized bass reflex port for less distortion at extreme frequencies
- Extremely low-noise and efficient power amplifier for clearer levels and less power consumption
- Wireless connection available with SubConnect MOD for compatible devices (i.e. ULTIMA 40 Active), or optional Subwoofer Wireless Transmitter
- Automatic on/off
- A wealth of configuration options (volume control, phase switch, auto dynamics and HP (high-pass) filter)
- Designed for AV receivers with or without THX licensing
Included components
-
2 × Pair Column Speaker LT 5A FR
–
Black
- 2 × power supply for LT 5A FR
- 2 × Spikes for LT 5 Mk2 FR (5 pcs.)
- 2 × Column Speaker LT 5A FR (pcs) – Black
- 1 × Centre Speaker LT 5 Mk2 C – Black
-
1 × Subwoofer S 6000 SW
–
Black
- 1 × Power cable – Black
Specifications
-
Centre Speaker LT 5 Mk2 C
A sophisticated, high-performance 3-way centre speaker with a brushed aluminium enclosure. The tweeter is positioned above the midrange driver as in the LT 5's accompanying column and satellite speaker. This identical construction creates a harmonious, immersive sound and excellent speech intelligibility. A waveguide and rounded front grille ensures the widest possible dispersion.
This speaker has keyhole brackets for wall mounting and comes with a heavy metal stand.-
Description Item Width 46 cm Height 16 cm Depth 14 cm Weight 5,7 kg -
Description Item High Level speaker inputs 1 Terminal clamps Gold-plated screw terminals Minimum amplifier output power recommended 40 W -
Description Item Suitable for AV receiver Yes Suitable for banana plug Yes Maximum cable diameter 4 mm Enclosure material Aluminium, steel Enclosure surface Brushed-aluminium, matte Magnetic shielding Yes Keyhole plate mounted Yes Integrated stand Yes Wall mounting brackets Yes Tweeter (number per enclosure) 1 Tweeter (diameter) 25 mm Tweeter (material) Fabric Midrange driver (number per enclosure) 1 Midrange driver (diameter) 80 mm Midrange driver (material) cellulose Woofer (number per enclosure) 2 Woofer (diameter) 130 mm Woofer (material) cellulose Continuous power handling (IEC - Long Term) 140 W Sensitivity (2.83 V / 1 m) 88 dB Frequency range 90 - 22000 Hz Peak power capacity (IEC - Short Term) 190 W Maximum sound pressure level 103 dB/1m Impedance 4 - 8 Ohm Crossover frequency to Woofer (recommended) 100 Hz Acoustic principle 3-way-system Enclosure type Closed Screw hole diameter 4 mm
Subwoofer S 6000 SW
High-end subwoofer with wireless connection option
-
Description Item Width 37 cm Height 47,4 cm Depth 54 cm Weight 23,6 kg -
Description Item Cinch input 1 -
Description Item Power supply voltage 230 V Automatic on/off Yes Maximum power consumption 250 W Mains cable - IEC connector (non-heating device) Yes Safety class 2 Storage for settings when disconnected Yes Standby-Function Yes Standby-Power consumption 0,4 W Input gain adjustment Yes Frequency regulator (range) 20 - 50 Hz Level control Yes Phase control Yes Power output capacity sinus (RMS) Bass 240 W Amplifier configuration 1.0 Amplifier technology Class D Amplifier channels 1 -
Description Item Lowest frequency (-3 dB) 25 Hz Suitable for AV receiver Yes Equalisation openings (pos.) Front Equalisation openings 1 Removable front cover Yes Frontfire Yes Enclosure material MDF Enclosure surface Laminated, matte Net internal volume 55 L Integrated stand Yes Woofer (number per enclosure) 1 Woofer (diameter) 300 mm Woofer (material) cellulose Frequency range 25 - 200 Hz Maximum sound pressure level 110 dB/1m Acoustic principle 1-way-system Enclosure type Bass reflex
-
Accessories
Necessary accessories
Connecting cables are not included with this delivery
